Fresh, neutral color – pairs well with light-colored decor. Stain-resistant and easy to clean. Long-term color stability – resists yellowing. Excellent moisture resistance.
| Parameter | Value | Description |
| Adjustable height range | 95 ~ 125 | Total height adjustment range |
| Minimum height H_min | 95 | Height when fully retracted |
| Maximum height H_max | 125 | Height when fully extended |
| Adjustment travel | 30 | 125 - 95 |
| Base mounting plate size | approx. 65×50 | Triangular / trapezoidal mounting plate |
| Number of mounting holes | 4 | Countersunk screw holes |
| Mounting hole center distance | approx. 45×30 | Horizontal / vertical center distance |
| Main cylinder diameter | Φ35 | Outer diameter of thick foot body |
| Top support disc diameter | Φ38 | Support surface connected to cabinet bottom plate |
| Top center hole | Φ8 | For reinforcement or positioning |
| Side wall thickness | 2.5 | Plastic body wall thickness |
| Base thickness | 5 | Mounting plate thickness |
Choose our tailored Furniture Hardware & Fitting Solutions to upgrade every corner of your space efficiently and perfectly.
